Gripper Products

GR Series
The GR-Series has a double acting piston attached to a cross bar by a connecting rod. The linear movement of the piston is transformed into angular movement of the jaws through a double toggle link mechanism.

AG Series
The AG series angular gripper utilizes a double acting piston with a dual pivot system. The piston has a single center pivot that drives each gripper jaw open and closed.

MPG5 Series

The MPG5 Series gripper is designed for pick & place of small pieces. The cutting edge design of the MPG5 allow for manifold mounting a series of MPG5’s in line without the concerns of space for fittings.

RG Series
The NRG series gripper offers both synchronized and compliant (non-synchronized) movement. Synchronized Motion: Two opposing pistons share a common bore.

PG Series
The PG series is low profile with true parallel motion that is generated by a pinion mechanism powered by a double acting piston. Body: Hardcoat Anodized, PTFE impregnated inside & out.

TJ Series
The TJ Series Grippers provide high grip force in a compact design. Shielded design make the TJ series ideal for machine loading and unloading.

PG6J80 Series
The PG6J80 series 6 finger gripper design utilizes a dual acting piston to open and close gripper jaws. All six jaws are synchronized for accurate positioning.

WBG Series
The WBG series utilizes independent pistons to power the jaws open and closed. Jaws utilize a rack & pinion for synchronization which are in`dependent from force rods and support rods.

WG Series
The WG series, (double guided wedge parallel grippers), achieves synchronous motion with a double acting piston attached via the piston shaft to a double sided wedge.

RPG Series
The RPG series has true parallel motion that is generated by a double acting piston attached to the pinion mechanism with a linkage that is guided in the body for precise centering.
